P1.25,P2,P3 LED full color screen

Products > LED Display > P1.25,P2,P3 LED full color screen

P1.25,P2,P3 LED full color screen

Parameter

  Model  P1.56  P2  P3
  Pixel pitch  1.56mm  2mm  3mm
  Panel resolution  256x192  320x320  213x213
  Led quantity /panel  409600dot/m²  250000dot/m²  111111dot/m²
  Led encapsulation  SMD 1010  SMD 1515  SMD 2121
  Panel dimension  400x300x60mm  640x640x80mm  640x640x80mm
  Brightness  ≧800cd/m²  ≧1000cd/m²  ≧1000cd/m²
  Contrast  6000:1  4000:1  4000:1
  Panel weight  4Kg  9.6Kg  9.2Kg
  Grey scale  16bit  14bit  14bit
  Refresh rate  3840Hz  3840Hz  3840Hz
  Max power consumption  550W/㎡  410W/㎡  351W/㎡
  Average power consumption  266W/㎡  205W/㎡  175W/㎡
  Pixel configuration  3-IN-1 SMD
  AC Operating Voltage  AC 110-240V  50/60Hz
  Operating Temp/Humidity  -20~50/10~85% RH
  Viewing angle  160°/160°
  IP rating  IP40(Front)
  Tenure life of lamp  100,000 Hours
  Certificates  ISO9001、RoHS、CE、FCC、CECP、CCC
